Non-Insulated Flat Blade Terminals Electrical Crimp Terminal BDBN
Specification:
Material: Copper, Tin-plated Copper
Certification: CE, RoHS, UL Approved
Working Temperature: -40 degrees to 80-degree
Non-Insulated Flat Blade Terminals can be crimped or soldered, widely used in the electrical wire connecting of the switchboard, mechanical equipment factory and so on
| Insulated square：0.5～1.5mm²(AWG22～16)Max. current: lmax=19A | |||||
| Item No | DIMENSION | ||||
| B | L | F | D | d | |
| mm | mm | mm | mm | mm | |
| BDBN1.25-10 | 2.3 | 14.8 | 10 | 3.4 | 1.7 |
| BDBN1.25-11 | 3 | 15.8 | 11 | ||
| BDBN1.25-14 | 3 | 18.8 | 14 | ||
| BDBN1.25-18 | 2.3 | 22.8 | 18 | ||
| Insulated square：1.5～2.5mm²(AWG16～14)Max. current: lmax=19A | |||||
| Item No | DIMENSION | ||||
| B | L | F | D | d | |
| mm | mm | mm | mm | mm | |
| BDBN2-9 | 2.3 | 13.8 | 9 | 4.1 | 2.3 |
| BDBN2-18 | 2.3 | 22.8 | 18 | ||
| Insulated square：4～6mm²(AWG12～10)Max. current: lmax=48A | |||||
| Item No | DIMENSION | ||||
| B | L | F | D | d | |
| mm | mm | mm | mm | mm | |
| BDBN5.5-10 | 2.8 | 14.8 | 13 | 5.6 | 3.4 |
| BDBN5.5-14 | 4.5 | 21 | |||
| BDBN5.5-18 | 4.5 | 23 | |||
| BDBN8-14 | 5 | 22.5 | 14 | 7.2 | 4.5 |
| BDBN14-16 | 6 | 30.6 | 16 | 9 | 6.5 |
| Insulated square：6～10mm²(AWG8)Max. current: lmax=62A | |||||
| Item No | DIMENSION | ||||
| B | L | F | D | d | |
| mm | mm | mm | mm | mm | |
| BDBN8-14 | 5 | 22.5 | 14 | 7.2 | 4.5 |
| Insulated square：10～16mm²(AWG6)Max. current: lmax=88A | |||||
| Item No | DIMENSION | ||||
| B | L | F | D | d | |
| mm | mm | mm | mm | mm | |
| BDBN14-16 | 6 | 30.6 | 16 | 9 | 6.5 |
